The Underwater Borehole Inspection Camera is a professional tool designed for visual inspections inside wells, boreholes, and other deep, narrow vertical shafts. Its rugged camera system, deployed via a flexible cable, provides high-resolution images and video of the well's interior, helping users accurately assess the well's overall condition. The underwater camera is also a versatile and durable device equipped with a 50mm lens and pan and tilt functions, allowing users to capture clear and detailed images and video of the underwater environment. Whether used for marine research, underwater inspections, or recreational diving, this camera provides users with a precise and convenient exploration and recording tool, making it an indispensable and valuable assistant in underwater operations.
Why Choose the Pan Tilt Borehole Cameras?
1. 360-degree coverage: The ability to pan (rotate horizontally) and tilt (move vertically) the camera head provides a comprehensive 360-degree view of the borehole walls. This eliminates blind spots and allows for a more thorough examination than a fixed-view camera.
2. Targeted inspection: Pan-tilt control allows the operator to investigate specific features, such as fractures, perforations, or geological stratification, in detail. You can pause and focus on areas of interest for a closer look, ensuring no defect is missed.
3. Versatility in complex environments: For well casing inspections, the pan-tilt head can be maneuvered to examine the condition of casing joints and screen openings. In open boreholes, it can investigate fractures, rock formations, and the movement of groundwater.
4. Manual focus: Our 50mm borehole camera systems feature manual focus capability, enabling operators to achieve crisp images of objects at varying distances, from close-up details of corrosion to wider views of the borehole.
2. Targeted inspection: Pan-tilt control allows the operator to investigate specific features, such as fractures, perforations, or geological stratification, in detail. You can pause and focus on areas of interest for a closer look, ensuring no defect is missed.
3. Versatility in complex environments: For well casing inspections, the pan-tilt head can be maneuvered to examine the condition of casing joints and screen openings. In open boreholes, it can investigate fractures, rock formations, and the movement of groundwater.
4. Manual focus: Our 50mm borehole camera systems feature manual focus capability, enabling operators to achieve crisp images of objects at varying distances, from close-up details of corrosion to wider views of the borehole.
Technical Parameters
| Camera Head Size | Φ50mm*154mm |
| Camera Pixel | 1.3MP Pixel |
| Waterproof Level | IP68 |
| View Range | 120° |
| Rotation | Pan 360°, Tilt 180° |
| Screen Size | 13-Inch HD IPS LCD Screen |
| Keyboard | USB Wireless Keyboard Real-Time Typewriting |
| Meter Counter | Digital Meter Counter |
| Battery | Built-in 8800mA Rechargeable Li-ion Battery Pack |
| Cable | Φ8mm 100m-200m Option Flexible Cable |
Applications and Use Cases
Underwater borehole cameras are vital for a wide range of industries and tasks, including:
**Water wells**: Inspecting well casings for damage like cracks or corrosion, assessing sediment build-up, and locating lost equipment like pumps.
**Mining and geology**: Viewing rock formations, geological structures, and fractures within boreholes for hydrologic investigations and mineral exploration.
**Civil and geotechnical engineering**: Inspecting pile foundations and shafts to assess their integrity.
**Environmental studies**: Monitoring groundwater conditions and assessing contamination levels by observing the presence of foreign objects or bacterial growth.
**Lost tool recovery**: Guiding the retrieval of equipment or tools that have been dropped or lost in a borehole.
If you have similar challenges in fields like water well inspection, mineral exploration, civil engineering, and environmental research, you may need a professional underwater borehole camera to help you conduct precise inspections. We understand that choosing the right inspection equipment can be confusing, especially since each project's requirements vary. If you're unsure about your selection, please feel free to contact us. Please email us at info@bestdertech.com to share your specific needs. Our professional team will recommend the most suitable inspection camera based on your specific situation to ensure a smooth and successful execution. We look forward to providing you with professional equipment support!
